Ignition Server Requirements

Applies to: Windows Server 2019

Connect Ignition to an MQTT Server. The Ignition MQTT Engine Module gives Ignition the ability to bidirectionally communicate with an MQTT server and share that data with any Ignition client. 4 Build and Deploy Ignition Applications. With Ignition, you can build an MQTT infrastructure, design any kind of industrial application, and deploy it to. Connect, Design, Deploy Without Limits! Ignition is unlimited, so for the low cost of one server license you can seamlessly connect all your data, design any kind of industrial application with ease, and instantly web-deploy unlimited industrial and mobile clients to anyone, anywhere — all from one universal platform for industrial automation.

This topic outlines the minimum system requirements to run Windows Server® 2019.

• Ignition itself is a modular industrial applications server. So it's installed as server software and is web-based, web-managed and has web launch designers and clients. You will need to install software in a single place called the server.
• As if Ignition 8, Java comes prepackaged with the Ignition installation. So we don't need to install or manage it separately. So we can see that the Installer has finished running and we're ready to start the Ignition service. So I'm going to click on the finish button which will go ahead and start Ignition.
• Today, most servers are 64-bit which allows essentially endless amounts of RAM for us to use (24TB in Windows Server 2016). If using a 64-bit instance of Java, there are two places that you can up the allotted memory for Ignition: the gateway server and the client.

Review system requirements

The following are estimated system requirements Windows Server 2019. If your computer has less than the minimum requirements, you will not be able to install this product correctly. Actual requirements will vary based on your system configuration and the applications and features you install.

Unless otherwise specified, these minimum system requirements apply to all installation options (Server Core, Server with Desktop Experience, and Nano Server) and both Standard and Datacenter editions.

Important

The highly diverse scope of potential deployments makes it unrealistic to state recommended system requirements that would be generally applicable. Consult documentation for each of the server roles you intend to deploy for more details about the resource needs of particular server roles. For the best results, conduct test deployments to determine appropriate system requirements for your particular deployment scenarios.

Processor

Processor performance depends not only on the clock frequency of the processor, but also on the number of processor cores and the size of the processor cache. The following are the processor requirements for this product:

Minimum:

• 1.4 GHz 64-bit processor
• Compatible with x64 instruction set
• Supports NX and DEP
• Supports CMPXCHG16b, LAHF/SAHF, and PrefetchW
• Supports Second Level Address Translation (EPT or NPT)

Coreinfo is a tool you can use to confirm which of these capabilities your CPU has.

RAM

The following are the estimated RAM requirements for this product:

Minimum:

• 512 MB (2 GB for Server with Desktop Experience installation option)
• ECC (Error Correcting Code) type or similar technology, for physical host deployments

Important

If you create a virtual machine with the minimum supported hardware parameters (1 processor core and 512 MB RAM) and then attempt to install this release on the virtual machine, Setup will fail.

To avoid this, do one of the following:

• Allocate more than 800 MB RAM to the virtual machine you intend to install this release on. Once Setup has completed, you can change the allocation to as little as 512 MB RAM, depending on the actual server configuration. If you've modified the boot image for Setup with addition languages and updates, you may need to allocate more than 800 MB RAM in order to complete the installation
• Interrupt the boot process of this release on the virtual machine with SHIFT+F10. In the command prompt that opens, use Diskpart.exe to create and format an installation partition. Run Wpeutil createpagefile /path=C:pf.sys (assuming the installation partition you created was C:). Close the command prompt and proceed with Setup.

Storage controller and disk space requirements

Computers that run Windows Server 2019 must include a storage adapter that is compliant with the PCI Express architecture specification. Persistent storage devices on servers classified as hard disk drives must not be PATA. Windows Server 2019 does not allow ATA/PATA/IDE/EIDE for boot, page, or data drives.

The following are the estimated minimum disk space requirements for the system partition.

Minimum: 32 GB

Note

Be aware that 32 GB should be considered an absolute minimum value for successful installation. This minimum should allow you to install Windows Server 2019 in Server Core mode, with the Web Services (IIS) server role. A server in Server Core mode is about 4 GB smaller than the same server in Server with a GUI mode.

The system partition will need extra space for any of the following circumstances:

• If you install the system over a network.
• Computers with more than 16 GB of RAM will require more disk space for paging, hibernation, and dump files.

Network adapter requirements

Network adapters used with this release should include these features:

Minimum:

• An Ethernet adapter capable of at least gigabit throughput
• Compliant with the PCI Express architecture specification.

A network adapter that supports network debugging (KDNet) is useful, but not a minimum requirement.

A network adapter that supports the Pre-boot Execution Environment (PXE) is useful, but not a minimum requirement.

Other requirements

Computers running this release also must have the following:

• DVD drive (if you intend to install the operating system from DVD media)

Ignition System Requirements

The following items are not strictly required, but are necessary for certain features:

• UEFI 2.3.1c-based system and firmware that supports secure boot

• Trusted Platform Module

• Graphics device and monitor capable of Super VGA (1024 x 768) or higher-resolution

• Keyboard and Microsoft® mouse (or other compatible pointing device)

• Internet access (fees may apply)

Ignition Minimum Requirements

Note

A Trusted Platform Module (TPM) chip is not strictly required to install this release, though it is necessary in order to use certain features such as BitLocker Drive Encryption. If your computer uses TPM, it must meet these requirements:

Ignition Server Requirements Pdf

• Hardware-based TPMs must implement version 2.0 of the TPM specification.
• TPMs that implement version 2.0 must have an EK certificate that is either pre-provisioned to the TPM by the hardware vendor or be capable of being retrieved by the device during the first boot.
• TPMs that implement version 2.0 must ship with SHA-256 PCR banks and implement PCRs 0 through 23 for SHA-256. It is acceptable to ship TPMs with a single switchable PCR bank that can be used for both SHA-1 and SHA-256 measurements.
• A UEFI option to turn off the TPM is not a requirement.
